KUEP-7D15-24 by te connectivity / p-b brand
DATA SHEET

KUEP-7D15-24

TE Connectivity / P&B Brand

Electromechanical Relay 24VDC 320Ohm 10A DPST-NO(38.89x35.71x55.55)mm Plain Case Industrial Relay .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUEP-7D15-24
Alias/AKA:
1-1393114-1
RoHS:
Yes
HTS:
8536490080
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPST-NO
Maximum Current Rating:
10 A
Mounting:
Plain Case
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
320 Ohm
The TE Connectivity / P&B Brand KUEP-7D15-24 is a high-quality electromechanical relay designed for industrial applications. With a coil voltage of 24VDC and a resistance of 320 Ohms, this relay provides reliable and efficient switching capabilities. It features a DPST-NO configuration, allowing for two independent normally open contacts. The compact dimensions of 38.89x35.71x55.55mm make it suitable for space-constrained environments. Enclosed in a plain case, this industrial relay offers excellent protection against external elements and is built to withstand harsh operating conditions. With a maximum current rating of 10A, the KUEP-7D15-24 is a sturdy and dependable solution for various industrial control systems.
Product Highlights:
  • KUEP Series
  • Contact Arrangement = 2 Form A, DPST-NO, 2 N/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
KUEP7D1524
IN STOCK: 82
Can Ship immediately
On Order:
150   can ship 2/24/25
Factory Lead-Time
17 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$32.28
$32.280
5
$30.09
$150.450
25
$26.99
$674.750
50
$23.56
$1,178.000
100
$23.33
$2,333.000
250
$22.87
$5,717.500
500 +
$22.64
$11,320.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
