OJE-SH-112HM,000 by te connectivity / p-b brand
DATA SHEET

OJE-SH-112HM,000

TE Connectivity / P&B Brand

3-10 Amp Miniature,PC Board Relay .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
OJE-SH-112HM,000
Alias/AKA:
1461402-6
RoHS:
Yes
HTS:
8536490080
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
10 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-30 to 60 °C
Coil Resistance:
320 Ohm
The OJE-SH-112HM,000 is a versatile and reliable miniature PC board relay from TE Connectivity / P&B Brand. With a current rating of 3-10 Amps, this compact relay is designed to handle a wide range of applications. It is constructed with high-quality materials to ensure durability and long-lasting performance. This relay is easy to install and features a compact design that saves valuable space on the PCB. Whether used in automotive, industrial, or consumer electronics, the OJE-SH-112HM,000 offers dependable and efficient switching capabilities.
Product Highlights:
  • OJE Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
OJESH112HM000
IN STOCK: 10,994
Ships today, if you order in
Minimum Order:
100
Multiple:
100
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$1.120
$112.000
300
$1.069
$320.700
500
$1.044
$522.000
1,000
$1.034
$1,034.000
2,500
$1.023
$2,557.500
5,000
$1.005
$5,025.000
7,500
$0.995
$7,462.500
10,000 +
$0.985
$9,850.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
