DATA SHEET

PCN-105D3MHZ,000

TE Connectivity / P&B Brand

Power Relay 5VDC 3A SPST-NO(20mm 5mm 12.5mm) THT .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
PCN-105D3MHZ,000
Alias/AKA:
3-1461491-0
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
3 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-30 to 70 °C
Coil Resistance:
208 Ohm
The TE Connectivity / P&B Brand part PCN-105D3MHZ,000 is a compact and reliable power relay designed for electronic applications. With a low operating voltage of 5VDC and a maximum current of 3A, this relay provides a dependable switch for controlling various electrical circuits. The SPST-NO (Single Pole Single Throw Normally Open) configuration offers a simple and versatile connection, while the through-hole technology (THT) mounting style ensures secure and convenient installation. Measuring just 20mm x 5mm x 12.5mm, this power relay is compact and space-saving, making it an excellent choice for compact electronic designs. Trust in the TE Connectivity / P&B Brand PCN-105D3MHZ,000 to deliver efficient and reliable performance in your power control applications.
Product Highlights:
  • PCN Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 3 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
PCN105D3MHZ000
IN STOCK: 5,535
Can Ship immediately
Minimum Order:
25
Multiple:
25
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$3.16
$79.000
100
$1.94
$194.000
250
$1.91
$477.500
500
$1.88
$940.000
1,000
$1.86
$1,860.000
2,500
$1.82
$4,550.000
5,000
$1.79
$8,950.000
7,500 +
$1.76
$13,200.000
Please Note: Item may be subject to tariff fee if shipping within the United States
