RT314730 by te connectivity / p-b brand
DATA SHEET

RT314730

TE Connectivity / P&B Brand

Power PCB Relay - 1 form C (CO) - 230VAC Coil - 16A Contact Rating - 400VAC Switching - Pinning 5mm - Flux Proof - PC Pin - Through Hole. .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RT314730
Alias/AKA:
1393240-7
RoHS:
Yes
HTS:
8536490080
COO:
AT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
230 V
DC Coil Voltage:
N/A
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
32.5 KOhm
The RT314730 from TE Connectivity / P&B Brand is through hole mounting power PCB relay with 1 form C (CO) contact arrangement, 230VAC coil voltage and 32.5 kOhms coil resistance. This flux proof relay has 5mm pinning, silver nickel (AgNi) contacts, 16A contact current rating, 400VAC maximum switching voltage and PC pin termination. Operating temperature range is from -40°C to 70°C.
Product Highlights:
  • RT1 Series
  • Contact Arrangement = 1 Form C, SPDT, 1 C/O
  • Contact Current Rating = 16 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 230 VAC
Search Keywords:
RT314730
IN STOCK: 10,824
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.99
$39.950
25
$4.45
$111.250
100
$4.27
$427.000
250
$4.21
$1,052.500
500
$4.15
$2,075.000
1,000
$4.09
$4,090.000
2,500
$4.02
$10,050.000
5,000 +
$3.96
$19,800.000
