RT424005 by te connectivity / p-b brand
DATA SHEET

RT424005

TE Connectivity / P&B Brand

Power Relay 5VDC 8A DPDT(29x12.7x15.7)mm THT .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RT424005
Alias/AKA:
5-1393243-9
RoHS:
Yes
HTS:
8536490050
COO:
AT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
8 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
62 Ohm
The TE Connectivity / P&B Brand RT424005 is a compact power relay designed to efficiently control electrical circuits. With a coil voltage of 5VDC, this relay is capable of handling currents up to 8A. Its double pole double throw (DPDT) configuration allows for multiple switching options.Measuring at just 29mm in length, 12.7mm in width, and 15.7mm in height, this through-hole mounted relay offers a space-saving solution for various applications. Its small size and dependable performance make it ideal for use in automotive, industrial, and general-purpose power control systems.Whether you need to switch power sources, control motor operations, or manage lighting circuits, the TE Connectivity / P&B Brand RT424005 power relay provides a reliable and efficient solution.
Product Highlights:
  • RT2 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 8 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
RT424005
IN STOCK: 25,680
Ships today, if you order in
Minimum Order:
20
Multiple:
20
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
20
$3.00
$60.000
60
$2.94
$176.400
260
$2.69
$699.400
500
$2.60
$1,300.000
1,000
$2.46
$2,460.000
2,500
$2.35
$5,875.000
5,000
$2.32
$11,600.000
7,500 +
$2.28
$17,100.000
