RTD34012 by te connectivity / p-b brand
DATA SHEET

RTD34012

TE Connectivity / P&B Brand

General Purpose Relay - SPST-NO (1 Form A) - 12VDC Coil - 16A Contact - 400VAC Switching - Non Latching Coil - PC Pin - Through Hole. .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RTD34012
Alias/AKA:
3-1419108-5
RoHS:
Yes
HTS:
8536490075
COO:
AT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
360 Ohm
The RTD34012 is sealed general purpose relay with operating temperature range from -40°C to 85°C.
Product Highlights:
  • RT1 Series
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Contact Current Rating = 16 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
RTD34012
  Possible Replacement options available.  See Alternatives
IN STOCK: 18,380
Ships today, if you order in
Minimum Order:
10
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.80
$28.000
50
$1.79
$89.500
250
$1.74
$435.000
500
$1.72
$860.000
1,000
$1.62
$1,620.000
2,500
$1.58
$3,950.000
5,000
$1.54
$7,700.000
7,500 +
$1.52
$11,400.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
