RTE24005F by te connectivity / p-b brand
DATA SHEET

RTE24005F

TE Connectivity / P&B Brand

Power Relay 5VDC 8A DPDT(29mm 12.7mm 15.7mm) THT .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RTE24005F
Alias/AKA:
4-1419108-0
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
62 Ohm
The RTE24005F is a high-quality power relay from TE Connectivity / P&B Brand, designed to provide reliable switching performance in various applications. This DPDT (double-pole, double-throw) relay has a compact form factor, measuring 29mm in length, 12.7mm in width, and 15.7mm in height. With a coil voltage of 5VDC and a contact rating of 8A, this relay is capable of handling moderate to high-power loads. It features through-hole technology (THT) for easy installation onto circuit boards. Whether it's used in industrial control systems, HVAC equipment, or automotive applications, the RTE24005F offers durable construction and efficient operation.
Product Highlights:
  • RT2 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 8 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
RTE24005F
IN STOCK: 37,707
Ships today, if you order in
Minimum Order:
20
Multiple:
20
Factory Lead-Time
21 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
20
$2.49
$49.800
60
$2.42
$145.200
100
$2.38
$238.000
260
$2.35
$611.000
500
$2.31
$1,155.000
1,000
$2.28
$2,280.000
2,500
$2.24
$5,600.000
5,000 +
$2.21
$11,050.000
Suppliers Standard Package
