V23105A5505A201 by te connectivity / p-b brand
DATA SHEET

V23105A5505A201

TE Connectivity / P&B Brand

Signal Relay 24VDC 3A DPDT( (20.2mm 10mm 11mm)) THT .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
V23105A5505A201
Alias/AKA:
2-1393793-1
RoHS:
Yes
HTS:
8536410050
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
3 A
Mounting:
Through Hole
Termination Style:
PC Pin
Operating Temperature:
-40 to 85 °C
Coil Resistance:
1.05 KOhm
Life Cycle:
Discontinued
TE Connectivity / P&B Brand part V23105A5505A201 is a high-quality signal relay that is designed to handle 24VDC and deliver a maximum current of 3A. This DPDT (double-pole double-throw) relay is ideal for a range of applications that require switching signals or controlling circuits. With its compact dimensions of 20.2mm length, 10mm width, and 11mm height, this relay can easily fit into tight spaces on printed circuit boards. The Through-Hole Technology (THT) allows for easy installation and secure soldering connections. This signal relay offers excellent performance, reliability, and durability, making it a perfect choice for electronic projects and industrial applications.
Product Highlights:
  • V23105 / D2n Relay Series
  • DC Actuating System
  • Input Voltage = 24 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 3 Amps.
Search Keywords:
V23105A5505A201
  This product is discontinued, but still in stock
IN STOCK: 10,529
Ships today, if you order in
Minimum Order:
25
Multiple:
25
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$2.92
$73.000
100
$2.87
$287.000
250
$2.83
$707.500
500
$2.79
$1,395.000
1,000
$2.74
$2,740.000
2,500
$2.70
$6,750.000
5,000
$2.66
$13,300.000
7,500 +
$2.62
$19,650.000
Suppliers Standard Package
Older Equivalent
2-1393793-1
2-1393793-1
