W58-XB1A4A-30 by TE Connectivity / P-B Brand
DATA SHEET

W58-XB1A4A-30

TE Connectivity / P-B Brand

Circuit Breaker Thermal 1Pole 30A 250VAC/50VDC .. see full description

  • RoHS Compliant
  • Tray Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P-B Brand
Part No:
W58-XB1A4A-30
Alias/AKA:
1-1393249-6
RoHS:
Yes
HTS:
8536200020
COO:
CN
ECCN:
EAR99
Package Type:
Tray
Type:
Thermal
Voltage Rating:
250,50 VAC|VDC
Number of Poles:
1
Current Rating:
30 A
Terminal Design:
Quick Connect
Operating Temperature:
N/A
Mounting:
Panel Mount
The 1-1393249-6 is a 30A push to reset only Thermal Circuit Breaker with maximum operating voltage is 50VDC or 250VAC, calibration will continuously carry 100% of rating, may trip between 101% and 145% of rated load, must trip at 145% at 25°C. Ten times rated current is resettable overload capacity, over 1500V RMS dielectric strength, endurance cycling is more than 1000 cycles at 200% of rated load. Quick connect 0.25-inch straight terminal with metal knurled nut or hex nut mounting hardware assembled to bushing. Cannot be manually tripped Button extends for visual trip indication Push button to reset breaker Single pole White with red rate marking, red trip band button Metal 7/16 x 0.5" long mounting bushing Applications Power Management
Product Highlights:
  • W58 Series
  • Number of Poles = 1
  • Actuator Style = Push to Reset
  • Current Rating = 30 Amps.
  • Button Color = White with Red Rate Marking, Red Trip Band
Search Keywords:
W58XB1A4A30
IN STOCK: 1,499
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
21 Weeks
