2024D1314-0 by te connectivity / raychem brand
DATA SHEET

2024D1314-0

TE Connectivity / Raychem Brand

2024D1314-0 .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
2024D1314-0
Alias/AKA:
CA1446-000
RoHS:
Yes
HTS:
8544200000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Impedance:
120 Ω
Wire Diameter:
.025 in
Cable Style:
Twisted Pair
Jacket Color:
Black
Capacitance:
12.5 pF/ft
Jacket Material:
Thermorad S
Dielektrischer Durchmesser:
1.73 mm
Dielectric Diameter:
.068 in
Shield Style:
Single
Velocity of Propagation:
77 %
Conductor Material:
Silver-Plated High Strength Copper
Overall Outside Diameter:
.183 in
Operating Temperature Range:
-65 – 125 °C, -85 – 257 °F
Cable Type:
Cheminax
Dielectric Material:
Rayfoam L
Product Type:
Wire Lead
Wire Size:
24 AWG
Shield Material:
Silver-Coated Copper
Cable Dielectric Diameter:
.068 in, 1.73 mm
Product Classification:
Cable - Coaxial
null:
24 AWG
TE Connectivity / Raychem's part 2024D1314-0 is a high-quality, reliable component designed for various applications. With precision engineering and durable materials, this part provides excellent performance and longevity. Trust TE Connectivity / Raychem for all your connectivity needs.
Search Keywords:
2024D13140
IN STOCK: 1,911
Can Ship immediately
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
625
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$9.05
$45.250
100
$7.31
$731.000
250
$7.22
$1,805.000
625
$7.00
$4,375.000
1,250
$6.82
$8,525.000
1,875
$6.75
$12,656.250
2,500 +
$6.68
$16,700.000
