CCR-33S10-TN by teledyne coax
DATA SHEET

CCR-33S10-TN

Teledyne Coax

RF Switch Commercial - 50 Ohms - 28VDC Coil - DC-18GHz - Failsafe - SPDT - SMA-Female - Opt: TTL-Drivers+Diodes Narrow-Body .. see full description

RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Teledyne Coax
Part No:
CCR-33S10-TN
RoHS:
No
HTS:
8536490050
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Impedance (Ohms):
50
Switch Configuration:
1P2T (SPDT)
Connector:
SMA Female
Actuator Feature:
Failsafe
Typical Operating Supply Voltage:
28 VDC
Actuation Current (mA - Typ):
90
Maximum Frequency:
18 GHz
Insertion Loss - Max Frequency (dB):
0.4 (Typ)
Isolation - Max Frequency (dB):
65 (Typ)
Insertion Loss - Min Frequency (dB):
0.1 (Typ)
Isolation - Min Frequency (dB):
90 (Typ)
Indicator Contacts:
N
Self-Cutoff:
Not App
Coil Transient Suppression Diodes:
Y
TTL Drivers:
Y
Decoders:
Not App
D-Sub Connector:
N
Moisture Seal:
N
Narrow Body:
Y
Positve Common:
Not App
Operating Temperature:
-40 to 65 °C
The TELEDYNE COAX CCR-33S10-TN is a reliable and high-performing RF switch designed for commercial applications. With a 50 Ohm impedance, 28VDC coil, and an operating frequency range of DC-18GHz, this narrow-body switch offers exceptional performance for a wide variety of RF systems. Built with failsafe functionality, it ensures uninterrupted signal transmission even in critical situations. This model features a single-pole, double-throw (SPDT) configuration and an SMA-Female connector for easy integration into existing systems. Optional TTL drivers and diodes are also available, enhancing versatility and control. Trust the TELEDYNE COAX CCR-33S10-TN to deliver reliable and precise RF switching capabilities for your commercial applications.
Search Keywords:
CCR33S10TN
IN STOCK: 100
Ships today, if you order in
Factory Lead-Time
10 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$192.96
$192.960
3
$190.07
$570.210
5
$187.22
$936.100
10
$184.41
$1,844.100
25 +
$181.02
$4,525.500
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
