DATA SHEET

SP-70

Triad Magnetics

Audio Transformer 1:1 1000Vrms 72Ohm Prim. DCR 92Ohm Sec. DCR 4Term. PC Pin Thru-Hole .. see full description

RoHS Non-Compliant

Packaging

Request Programming Quote

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

Triad Magnetics

Part No:

SP-70

RoHS:

HTS:

8504408500

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Operating Frequency:

0.3 to 100 kHz

Frequency Response:

±2 dB

Turns Ratio:

1:1

Packaging:

N/A

Primary Side Voltage:

150 V

The TRIAD MAGNETICS SP-70 is a high-quality audio transformer designed for various audio applications. This transformer features a 1:1 turns ratio, allowing it to provide efficient impedance matching and signal transfer between audio devices. With a maximum voltage rating of 1000Vrms and a primary DC resistance of 72 Ohms, this transformer ensures excellent performance and reliability. The secondary DC resistance is measured at 92 Ohms, further enhancing signal integrity and minimizing losses. The transformer is equipped with 4-terminal PC pins for convenient and secure through-hole mounting, making it suitable for a range of audio equipment and installations.
