E13-50H by zf electronic systems
DATA SHEET

E13-50H

ZF Electronic Systems

Snap Action Switch - SPDT - Lever - 15A@125/250VAC 2A@48VDC - Quick Connect - Screw Mount .. see full description

RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E13-50H
Alias/AKA:
0E1350H0
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
672
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Thermoplastic Nylon/Lever
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
3.56 mm
Operating Force:
0.64 N
Termination Style:
Quick Connect
Dimension:
92.78 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A
The ZF Electronics Corp part E13-50H is a versatile and reliable snap action switch that is designed to be used in various applications. It features a single-pole double-throw (SPDT) configuration with a lever actuator.This snap action switch can handle a maximum current rating of 15A at 125/250VAC and 2A at 48VDC, making it suitable for a range of electrical circuits. It has quick connect terminals for easy and efficient installation.The E13-50H snap action switch is designed for screw mounting, providing a secure and stable connection. With its high-quality construction and precise functionality, this switch is built to withstand heavy-duty use and provide long-lasting performance.Whether in industrial equipment, appliances, or automotive applications, the ZF Electronics Corp part E13-50H snap action switch delivers reliable and efficient switching capabilities.
Product Highlights:
  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.
Search Keywords:
E1350H
IN STOCK: 606
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
20 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$8.449
$8.449
5
$7.681
$38.405
50
$4.935
$246.750
100
$4.539
$453.900
250
$4.422
$1,105.500
672
$4.311
$2,896.992
1,344
$4.268
$5,736.192
2,688
$4.225
$11,356.800
5,376 +
$4.183
$22,487.808
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
